TRANSFORMERS

WORKING PRINCIPLE -A transformer works on Faraday’s Law of Electromagnetic Induction. When an alternating voltage is applied to the primary winding, an alternating current produces a changing magnetic flux in the iron core. This changing flux links with the secondary winding and induces an EMF in it.

The basic voltage relationship is:

V₁ / V₂ = N₁ / N₂ Where:
V₁ = Primary voltage
V₂ = Secondary voltage
N₁ = Number of primary turns
N₂ = Number of secondary turns

MAIN PARTS OF A TRANSFORMER
MAGNETIC CORE – Provides a low-reluctance path for magnetic flux.
PRIMARY WINDING – Connected to the AC supply.
SECONDARY WINDING – Supplies the transformed voltage to the load.
INSULATION – Electrically separates windings and other components.
TRANSFORMER OIL – Used for insulation and cooling in oil-filled transformers.
TANK – Contains the core, windings and insulating oil.
RADIATORS – Dissipate heat from the transformer oil.
CONSERVATOR TANK – Allows expansion and contraction of transformer oil.
BREATHER – Prevents moisture from entering the conservator.
BUSHINGS – Provide insulated electrical connections through the transformer tank.


TYPES OF TRANSFORMERS

STEP-UP TRANSFORMER: Increases the output voltage.

STEP-DOWN TRANSFORMER: Decreases the output voltage.

ISOLATION TRANSFORMER: Provides electrical isolation between two circuits, normally with a 1:1 voltage ratio.

AUTO TRANSFORMER: Uses a common winding for both primary and secondary circuits.

THREE-PHASE TRANSFORMER: Used for three-phase power systems and industrial applications.

TRANSFORMER LOSSES-The main losses are:
Copper Loss – Due to resistance of primary and secondary windings.
Core/Iron Loss – Consists mainly of hysteresis and eddy-current losses.

Stray Losses – Caused by leakage flux inducing currents in surrounding metallic parts.

Dielectric Losses – Occur in the insulation.

Transformer Efficiency

Transformer efficiency is:

η = Output Power / Input Power × 100

A well-designed transformer can have very high efficiency because it has no rotating or moving parts.

Applications in Ships Transformers are commonly used onboard ships for:

  • Stepping down 440 V to 220 V or 110 V
  • Supplying lighting systems
  • Control and instrumentation circuits
  • Navigation equipment
  • Communication systems
  • Battery chargers
  • Emergency electrical systems
  • Isolation of sensitive electrical equipment
